Single Mode Simplex SC APC 2.0mm 3.0mm Fiber Optic Pigtail

Product Categories
Shenzhen CY COM Product Co., Ltd.
Contact Now

Single Mode Simplex SC APC 2.0mm 3.0mm Fiber Optic Pigtail

  • 1
  • 2

Brand Name : CY COM

Model Number : FC

Certification : RoHS,ISO9001

Place of Origin : Shenzhen China

MOQ : 10PCS

Price : 0.2USD-0.3USD

Payment Terms : L/C, T/T, Western Union

Supply Ability : 30000pcs per day

Delivery Time : 3-5 working days

Packaging Details : PE bag or plastic box and Carton box

Length : 1m or customized

Cable color : white,yellow,blue or customer request

Connector : FC

Cable diameter : 0.9mm/2.0mm/3.0mm

Jacket material : OFNP,PVC.LSZH

Contact Now

Single Mode Simplex SC APC 2.0mm 3.0mm Fiber Optic Pigtail
2.0mm or 3.0mm Pigtail,FC,RoHS Standard,with a zirconia ceramic ferrule with pre-polished PC,UPC,APC
Description:
Fiber optic pigtail are suited for equipment jumper cord, cross connects, and work area connections. All patch cables are manufactured using riser grade cable and are factory tested to make sure performance to meet Telcordia standards.
Features :
Complying with IEC, Telcordia GR-326-CORE, YD-T 1272.3-2005,standard.
Low insertion loss, high return loss
Good in repeatability and exchangeability
High dense connection, easy for operation
Application:
Telecommunication
Computer networks
CATV networks Active device termination
Instrumentation
Specification:
Parameter Insertion loss(typical) Return loss Operating wavelength Exchangeability Vibration Operating temperature Storage temperature
unit dB dB nm dB dB ℃ ℃
FC UPC ≤0.3 ≥50 1310, 1490,1550 ≤0.2 ≤0.2 -40~75 -45~85
APC ≤0.3 ≥60

Order Information:

1. Connector type: SC, LC, ST, FC, E2000, MTRJ, MU, DIN, D4

2. Fiber Type: SM(9/125um), OM1(62.5/125um), OM2(50/125um), OM3(50/125um), OM4(50/125um)

3. Cable count: Simplex or Duplex, bundle pigtail, ribbon pigtail

4. Diameter of cable: 3.0mm(2.8mm), 2.0mm(1.8mm), 0.9mm

5. Cable length: 2Meter, 5Meter, 10Meter, customized length

6. Cable color: Yellow for SM, Orange for OM1 & OM2, Aqua for OM3, Violet for OM4, customized color

7. Outer jacket:PVC Riser cable, PVC Plenum cable, LSZH cable

Single Mode Simplex SC APC 2.0mm 3.0mm Fiber Optic Pigtail

Single Mode Simplex SC APC 2.0mm 3.0mm Fiber Optic Pigtail

Single Mode Simplex SC APC 2.0mm 3.0mm Fiber Optic Pigtail
